INA FAG - UC20516INA - Bearing Insert 1" / 25.4x52x17mm INA FAG
INA FAG - UC20516INA - Bearing Insert 1" / 25.4x52x17mm INA FAG
INA FAG - UC20516INA - Bearing Insert 1" / 25.4x52x17mm INA FAG
INA FAG - UC20516INA - Bearing Insert 1" / 25.4x52x17mm INA FAG
INA FAG - UC20516INA - Bearing Insert 1" / 25.4x52x17mm INA FAG

In stock - ready to ship

Order now for delivery between 26 May and 29 May
Free shipping on orders over €60

Pay Securely with

INA FAG - UC20516INA - Bearing Insert 1" / 25.4x52x17mm INA FAG

INA FAG - UC20516INA - Bearing Insert 1" / 25.4x52x17mm INA FAG

€12.89

(Excl. VAT)

Price

(Excl. VAT)

€12.89

INA FAG
Ina-fag is a supplier of precision bearings and components for agricultural machinery. The brand offers high-quality bearings for tractors, harvesters, and other heavy-duty equipment. Ina-fag products are engineered to withstand harsh farming conditions and reduce maintenance needs. Shop more than 17,174 genuine Ina-fag spare parts.

Product Details

Brand
INA/FAG
Unit
Each
Properties
Both sides: extended inner ring with 2 adjusting screws Convex outer ring with lubricating holes Sealed on both sides
Thread type
Inch
Inside diameter
1 Inch
Thread diameter
1/8 Inch
dInside diameter
25,4 mm
Application range
Mobile mechanical engineering Stationary mechanical engineering
BInner ring width
34,1 mm
COuter ring width
17 mm
DOutside diameter
52 mm
Basic radial load static
7800 N
Basic radial load dynamic
14900 N
Ball centre to end distance
14,3 mm
Ball centre to grease hole distance
4,2 mm
Locking screw centre to end distance
5 mm
Ball centre to inner ring end distance
19,8 mm
Manufacturer
INA/FAG
