Kramp - EPL40350C - Cylinder Set
Kramp - EPL40350C - Cylinder Set
Kramp - EPL40350C - Cylinder Set
Kramp - EPL40350C - Cylinder Set

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping

Pay Securely with

Kramp - EPL40350C - Cylinder Set

Kramp - EPL40350C - Cylinder Set

€89.88

(Excl. VAT)

Price

(Excl. VAT)

€89.88

Product Description

Fully mounted Unique, innovative design Special circlip on piston All methods of mounting possible Pre-sprayed with primer Maximum radial load: 10% of the axial force Maximum operating pressure depends on the maximum buckling load The maximum buckling load can be found using the cylinder software
Kramp
Kramp is a leading distributor of spare parts and accessories for agricultural machinery. Their catalog includes wear parts, belts, and maintenance items for tractors and implements. Kramp ensures quick availability of critical components for farming operations. Shop more than 86,564 genuine Kramp spare parts.

Product Details

Brand
Kramp
Pros
Ready to use Long service life High level of operational reliability
Type
Single acting
Unit
Each
Width
25 mm
Series
EPL-C
Stroke
350 mm
Max. length
839 mm
BMin. length
489 mm
Rod diameter
40 mm
Rod material
Steel 20MnV6
Product details
Fully mounted Unique, innovative design Special circlip on piston All methods of mounting possible Pre-sprayed with primer Maximum radial load: 10% of the axial force Maximum operating pressure depends on the maximum buckling load The maximum buckling load can be found using the cylinder software
Nominal pressure
200 BAR
Cylinder material
Stainless steel 52.0
EOutside diameter
55 mm
Head nut material
Cast iron
Guide ring material
Plastic
Application category
Universal
JCylinder head length
86 mm
Max. working pressure
250 BAR
Rod surface roughness
0,2 µm
Rod surface treatment
Chromated
Oil connection material
Steel
Mounting type - rod connection
No mounting
Oil connection inside diameter
25 mm
HCylinder head outside diameter
70 mm
FCylinder end to rod end distance
40 mm
Mounting type - cylinder connection
No mounting
Cylinder end to mounting bush distance
25 mm
Cylinder material tolerance class code
H10
Mounting thread diameter - rod connection
3/8 Inch
DCylinder center to oil connection end distance
44,5 mm
Manufacturer
Kramp
