Home
Maintenance & Wear Parts
Roller Chains
Kramp - SD3420 - CHAINWHEEL DUPLEX 20 T.3/4
Kramp - SD3420 - CHAINWHEEL DUPLEX 20 T.3/4
Kramp - SD3420 - CHAINWHEEL DUPLEX 20 T.3/4
Kramp - SD3420 - CHAINWHEEL DUPLEX 20 T.3/4
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping on orders over €60

Pay Securely with

Kramp - SD3420 - CHAINWHEEL DUPLEX 20 T.3/4

Kramp - SD3420 - CHAINWHEEL DUPLEX 20 T.3/4

€14.74

(Excl. VAT)

Price

(Excl. VAT)

€14.74

Kramp
Kramp is a leading distributor of spare parts and accessories for agricultural machinery. Their catalog includes wear parts, belts, and maintenance items for tractors and implements. Kramp ensures quick availability of critical components for farming operations. Shop more than 86,606 genuine Kramp spare parts.

Product Details

Brand
Kramp
Bore
Yes
Type
Duplex
Unit
Each
BWidth
50 mm
Hub type
Hub one side
Material
Steel C45
Teeth width
10,8 mm
D3Hub diameter
100 mm
Technical info
Hub bore, keyway and tapped hole are optional Recommended maximum bore: D3 x 0.6 For type 12b2 chain
B0Bore diameter
20 mm
Chain size code
12 B-2
Number of teeth
20
D1Pitch diameter
121,78 mm
Application range
NOT suitable for chain ASA/DIN 8188
Sections distance
19,46 mm
Total teeth width
30,3 mm
D2Outside diameter
130 mm
Manufacturer
Kramp
