Non Branded - M1205MA18A - Plug 5 P. Male M12 Code-A

SKU: non-branded-m1205ma18a

Non Branded - M1205MA18A - Plug 5 P. Male M12 Code-A

€15.23€13.02 (Excl. VAT)

RRP:€16.24
Save €1.01

In stock - ready to ship

Order now for shipping within 2 to 4 business days

Shipping fee: €11.99 incl. VAT

Pay Securely with

Price

€15.23

Part Number
M1205MA18A
Type
Screw
Unit
Each
Series
M12
Housing colour
Black
Nominal voltage
60 V
Number of poles
5
Electric category
Sensor Signal
Operating current
4 A
Max cable diameter
6 mm
Min cable diameter
4 mm
Protection class IP
67
Max working temperature
85 °C
Min working temperature
-40 °C
Max. cable core diameter
0,75 mm
Min. cable core diameter
0,25 mm
Cable position type - connection no 1
Straight
Keying and rotation - connection no 1
A
Connection type male/female - connection no 1
Male
Manufacturer

The 5-pole M12 code-A male connector with part number M1205MA18A has straight cable entry and A-coding. It has a black housing and is rated IP67 for sensor signal use.
