Tsubaki - RSD501LAMBDA - Roller Chain Lambda ASA 50
Tsubaki - RSD501LAMBDA - Roller Chain Lambda ASA 50
Tsubaki - RSD501LAMBDA - Roller Chain Lambda ASA 50
Tsubaki - RSD501LAMBDA - Roller Chain Lambda ASA 50
Tsubaki - RSD501LAMBDA - Roller Chain Lambda ASA 50
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Tsubaki - RSD501LAMBDA - Roller Chain Lambda ASA 50

Tsubaki - RSD501LAMBDA - Roller Chain Lambda ASA 50

€111.85

(Excl. VAT)

Price

(Excl. VAT)

€111.85

Product Description

With Lambda technology With oil-impregnated sintered bush Specially coated pins Ring coined connecting links for maximum load
Tsubaki
Tsubaki manufactures high-performance chains and power transmission components for agricultural machinery. The brand specializes in durable roller chains, sprockets, and tensioners used in tractors and harvesting equipment. Its products are known for precision engineering and resistance to heavy loads in demanding farming conditions. Shop more than 330 genuine Tsubaki spare parts.

Product Details

Brand
Tsubaki
Type
Simplex
Unit
Metre
Weight
1,11 kg/m
pPitch
5/8 Inch
Size L1
10,75 mm
Size L2
12,45 mm
gHeight
15 mm
Benefits
Maintenance-free Longer service life
Pin length
24 mm
Properties
Starts and ends with an inner link.
DIN standard
8188
Qty. Rounding
0.01
Size code ASA
50
Size code ISO
10 A-1
Size code ANSI
50-1
Technical info
Must not be lubricated Chains are supplied in desired length (max. 3.05 m)
b1Width inside
9,26 mm
d2Pin diameter
5,09 mm
Product category
Roller chain
Application range
Ideal for chain drives that cannot or should not be lubricated Smooth drive, no load peaks
d1Roller diameter
10,16 mm
Thickness inner plate
2,4 mm
Thickness outer plate
2 mm
Manufacturer
Tsubaki
