Voss - EGESD22LM26WD - Rotating Adapter 22L - M26
Voss - EGESD22LM26WD - Rotating Adapter 22L - M26
Voss - EGESD22LM26WD - Rotating Adapter 22L - M26
Voss - EGESD22LM26WD - Rotating Adapter 22L - M26

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping on orders over €60

Pay Securely with

Voss - EGESD22LM26WD - Rotating Adapter 22L - M26

Voss - EGESD22LM26WD - Rotating Adapter 22L - M26

€8.02

(Excl. VAT)

Price

(Excl. VAT)

€8.02

Product Description

The VOSS EGESD22LM26WD is a genuine VOSS rotating adapter designed for hydraulic systems. This durable adapter features a 22L light series connection for 22 mm outer diameter tubes and M26x1.5 threads on both ends. Constructed from high-quality steel with a zinc-nickel plated finish, it ensures corrosion resistance and reliable performance. Rated for a maximum operating pressure of 315 bar, this adapter provides a secure and flexible connection in demanding applications.
Voss
Voss is a supplier of industrial and agricultural components, including hydraulic systems and fittings. The brand's products are used in tractor attachments, irrigation systems, and other farm machinery requiring reliable fluid handling. Its solutions ensure high performance and durability in demanding agricultural applications. Shop more than 2,632 genuine Voss spare parts.

Product Details

Brand
Voss
Pros
Reduced risk of leakage
Unit
Each
Shape
Straight - 2 connection sides
Series
22L
DIN standard
2401
Pipe diameter
22 mm
Seal material
Nitrile rubber [NBR]
Inside diameter
17 mm
Product details
WD = Pre-assembled with flexible seal Optimal cutting ring connection and functionality Multiple corrosion resistance
Surface treatment
Zinc, Nickel-plated
Connection 2, type
Swivel nut
Connection no 1 type
Seal ring
Max working pressure
250 BAR
Max. tightening torque
180 N·m
KConnection no 1 length
16 mm
Connection no 1 diameter
22 mm
Connection no 1 hex size
31,9 mm
Connection 2, thread type
Metric
Connection 2, thread pitch
2.00 mm
Connection no 1 thread type
Metric
S2Connection 2, wrench size
36.0 mm
Connection no 1 thread pitch
1.50 mm
Connection 2, thread diameter
M30
S1Connection no 1 wrench size
32.0 mm
Connection no 1 thread diameter
M26
Connection 2, type - male/female
Female
Connection no 1 type - male/female
Male
L1Connection 2, centre to end distance
32,5 mm
Manufacturer
Voss
