Walterscheid - 1692718 - Drive Shaft Eco

OEM Supplier

SKU: walterscheid-1692718

Walterscheid - 1692718 - Drive Shaft Eco

Last known price:

€160.46

Request a Quote

Pay Securely with

Request a Quote

The Walterscheid 1692718 W2300 Eco drive shaft is a genuine power transmission component designed for agricultural applications. Featuring a compressed length of 1010mm and an extended length of 1460mm, it ensures reliable power transfer. The shaft is equipped with a 30.2mm cross journal diameter and 80mm cross journal length. Both tractor and implement sides feature a 1 3/8" - 6 spline connection and a robust star tube profile. It delivers 35 kW (47 hp) at 540 rpm and 55 kW (75 hp) at 1000 rpm, weighing 14.2 kg.
Walterscheid
Walterscheid, founded in 1919 in Lohmar, Germany, has a long-standing history in power transmission technology. The company initially focused on components for agricultural machinery, quickly establishing itself as a leader in driveline systems. Today, Walterscheid Powertrain Group is a global leader in agricultural and off-highway driveline and intelligent system solutions, with its headquarters still located in Lohmar. The brand is renowned for its high-quality PTO (Power Take-Off) shafts, driveline systems, gearboxes, and coupling systems. These components are engineered for durability, efficiency, and safety, serving a wide range of agricultural machinery from tractors to various implements. Walterscheid's innovations often focus on enhancing power transfer, reducing vibration, and improving operational safety for farmers. Partao offers a comprehensive selection of Walterscheid components, including PTO Guards & Shields, Air Filters, Alternators, Axle Assemblies, and Ball Bearings. Over 66,302 genuine Walterscheid spare parts are available at Partao. Agricultural professionals worldwide trust Walterscheid for robust and reliable power transmission solutions. The company's commitment to engineering excellence ensures that its parts can withstand the demanding conditions of modern farming, contributing to the longevity and performance of agricultural equipment across diverse applications, from tillage to harvesting.

Part Numbers
1692718
Series
W2300 Eco
Compressed Length (mm)
1010
Extended Length (mm)
1460
Cross Journal Diameter (mm)
30.2
Cross Journal Length (mm)
80
Tractor Side Connection
1 3/8" - 6 spline
Implement Side Connection
1 3/8" - 6 spline
Profile Tube Type
Star tube
Power At 540 RPM (kW)
35
Power At 540 RPM (hp)
47
Power At 1000 RPM (kW)
55
Power At 1000 RPM (hp)
75
Weight (kg)
14.2
Quality
OEM Supplier
EAN
4048893005814
Manufacturer
walterscheid
