Walvoil - MC08Y023B - Pressure Relief Valve 12V
Walvoil - MC08Y023B - Pressure Relief Valve 12V
Walvoil - MC08Y023B - Pressure Relief Valve 12V
Walvoil - MC08Y023B - Pressure Relief Valve 12V
Walvoil - MC08Y023B - Pressure Relief Valve 12V
Walvoil - MC08Y023B - Pressure Relief Valve 12V

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping

Pay Securely with

Walvoil - MC08Y023B - Pressure Relief Valve 12V

Walvoil - MC08Y023B - Pressure Relief Valve 12V

€275.52

(Excl. VAT)

Price

(Excl. VAT)

€275.52

Product Description

This proportional pressure limiter, when system pressure is constantly changing, ensures a constant and reduced pressure at connection 1. To ensure this feature, it is crucial to return the compensation and leakage oil connection 3 pressure-free to the tank.
Walvoil
Walvoil designs and manufactures hydraulic components and systems for agricultural and industrial machinery. The brand specializes in valves, pumps, and steering units for tractors and off-road equipment. Its products ensure precise fluid control and reliability in heavy-duty farming operations. Shop more than 1,006 genuine Walvoil spare parts.

Product Details

Brand
Walvoil
Unit
Each
Cavity
CP8-2
Torque
30 N·m
Includes
Proportional coil 12 or 24V Proportional connector EMI-AC-01F must be ordered separately
Flow rate
1 l/min
Frequency
150-150 Hz
Extra info
As proportional pre-control in a load sensing system at low volume flow and high pressure
Voltage (DC)
12 V
ATotal length
105 mm
Max. pressure
350 BAR
Pressure range
80-350 BAR
BMounting length
27,5 mm
Wrench/spanner size
27.0 mm
Manufacturer
Walvoil
