Walvoil - VDSRL05012 - Sequence Valve VDSRL05 A 06S B
Walvoil - VDSRL05012 - Sequence Valve VDSRL05 A 06S B
Walvoil - VDSRL05012 - Sequence Valve VDSRL05 A 06S B
Walvoil - VDSRL05012 - Sequence Valve VDSRL05 A 06S B
Walvoil - VDSRL05012 - Sequence Valve VDSRL05 A 06S B
Walvoil - VDSRL05012 - Sequence Valve VDSRL05 A 06S B

In stock - ready to ship

Order now for delivery between 20 May and 23 May
Free shipping

Pay Securely with

Walvoil - VDSRL05012 - Sequence Valve VDSRL05 A 06S B

Walvoil - VDSRL05012 - Sequence Valve VDSRL05 A 06S B

€63.57

(Excl. VAT)

Price

(Excl. VAT)

€63.57

Product Description

High pressure and medium volume flow For inline mounting To be used as sequential switching Version: individual parts in housing Works from D to C Free flow from C to D The pressure setting depends on the load in C No external leakage connection
Walvoil
Walvoil designs and manufactures hydraulic components and systems for agricultural and industrial machinery. The brand specializes in valves, pumps, and steering units for tractors and off-road equipment. Its products ensure precise fluid control and reliability in heavy-duty farming operations. Shop more than 1,006 genuine Walvoil spare parts.

Product Details

Brand
Walvoil
Unit
Each
Includes
Aluminium enclosure Directly controlled pressure relief valve (VMP) Bypass check valve for free return
Housing width
35 mm
Housing height
70 mm
Housing length
80 mm
Max. flow rate
25 l/min
Adjustment type
Socket screw
Cartridge length
60 mm
Housing material
Aluminium
Max working pressure
210 BAR
Mounting holes diameter
6,5 mm
Adjustable pressure range
20-80 BAR
Connection thread diameter
3/8 Inch
Manufacturer
Walvoil
