Walvoil - VMPBL05003 - Pressure Control Valve VMP
Walvoil - VMPBL05003 - Pressure Control Valve VMP
Walvoil - VMPBL05003 - Pressure Control Valve VMP
Walvoil - VMPBL05003 - Pressure Control Valve VMP
Walvoil - VMPBL05003 - Pressure Control Valve VMP
Walvoil - VMPBL05003 - Pressure Control Valve VMP
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping on orders over €60

Pay Securely with

Walvoil - VMPBL05003 - Pressure Control Valve VMP

Walvoil - VMPBL05003 - Pressure Control Valve VMP

€38.83

(Excl. VAT)

Price

(Excl. VAT)

€38.83

Product Description

The Walvoil VMPBL05003 is a direct-acting, screw-in cartridge type pressure relief valve designed for hydraulic systems. It features 3/8" BSP ports and offers an adjustable pressure range from 50 to 300 bar. This valve is commonly used to protect hydraulic circuits from overpressure, ensuring system safety and longevity. Its robust construction makes it suitable for various agricultural, construction, and industrial machinery applications requiring reliable pressure control.
Walvoil
Walvoil designs and manufactures hydraulic components and systems for agricultural and industrial machinery. The brand specializes in valves, pumps, and steering units for tractors and off-road equipment. Its products ensure precise fluid control and reliability in heavy-duty farming operations. Shop more than 1,006 genuine Walvoil spare parts.

Product Details

Brand
Walvoil
Type
Spring-loaded valve
Unit
Each
Properties
Type: spring-loaded valve, direct control Opens from P to T Intermittent fast-reacting circuit
HTotal height
129 mm
CHousing width
35 mm
Max. flow rate
35 l/min
AHousing length
70 mm
Adjustment type
Socket screw
Connection type
Thread
Housing material
Aluminium
Application range
For installation between lines High pressure and moderate to high volume flow For use as a pump safety device
Max working pressure
210 BAR
Connection thread type
Inch
ZMounting holes diameter
6,5 mm
Adjustable pressure range
50-220 BAR
Connection thread diameter
3/8 Inch
Manufacturer
Walvoil
