White - OMP501515211 - Orbit Motor End Port

White - OMP501515211 - Orbit Motor End Port

White - OMP501515211 - Orbit Motor End Port

White - OMP501515211 - Orbit Motor End Port

White - OMP501515211 - Orbit Motor End Port

White - OMP501515211 - Orbit Motor End Port

Number of products

In stock - ready to ship

Order now for delivery between 20 May and 23 May

Free shipping

Pay Securely with

White - OMP501515211 - Orbit Motor End Port

White - OMP501515211 - Orbit Motor End Port

€355.16

(Excl. VAT)

Price

(Excl. VAT)

€355.16

Number of products

Product Details

Brand

Unit

Each

Benefits

Flexible

Max. power

10 kW

Properties

Robust and compact construction High axial and radial load carrying capacity of the axle High starting torque Pressure drop: P1 = operating pressure continuous, P2 = operating pressure intermittent, P3 = peak pressure

Shaft type

Straight parallel

Flange code

A2

Displacement

50 cm³/rev

Rotor length

6,5 mm

Sealing type

Standard

Housing length

132 mm

Max. flow rate

60 l/min

Shaft diameter

25 mm

Technical info

Seal can be ordered under no. OMP 9-AFD 98 (older series on request) Equipped with leakage oil connection so that the product can easily be used in series with other engines, can also be used in closed-centre hydraulic systems; P1 = operating pressure continuous, P2 = int. operating pressure max. 10%/min, P3= peak pressure

Application range

Wherever high torque and low speeds are required, e.g. for sweeping brushes, loader wagons, chain drives, spreaders, lawnmowers, winches, agricultural machinery, forestry machinery and construction machinery

Max pressure peak

225 BAR

Shaft thread type

Metric

Max rotation speed

1230 r/min

Min rotation speed

10 r/min

Main port thread type

BSP

Max continuous torque

93 N·m

Shaft thread diameter

M10

Number of mounting holes

4

Main port thread diameter

1/2 Inch

Max. continous working pressure

140 BAR

Max intermittend working pressure

175 BAR

Manufacturer

White
