Emmegi - OK2015K12202 - Emmegi Oil Cooler 12V 38-50 grC 2015

SKU: emmegi-ok2015k12202

Emmegi - OK2015K12202 - Emmegi Oil Cooler 12V 38-50 grC 2015

€410.96€351.25 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 2 to 4 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€410.96

Brand
Emmegi
Part Numbers
OK2015K12202
Pros
Compact build-in Complete unit Increased efficiency Long component service life
Unit
Each
Includes
Aluminium radiator Support Impeller / electric motor, voltage depends on version Temperature switch Connector for connecting temperature switch/DC motor
Properties
Coolers are equipped with thermostats (38-50ºC) as standard Motor is switched by relay
Consists of
Aluminium cooler Support Fan/electric motor, voltage depends on version 40-48ºC temperature switch Plug for connecting temperature switch/DC motor
Product details
Temperature switch 38-50°C Maximum temperature 120°C The motor must be switched via a relay
Insulation class
64
Long description
Oil coolers or heat exchangers are used to increase the exchange of heat between oil and ambient air. The coolers are fitted with a thermostat 38-50°C as standard. A controlled oil temperature increases the efficiency and lifetime of components in the system.
Application range
For heat exchange between oil and cooling air in hydraulic systems Improves heat exchange between oil and environment
Max. working flow
70 l/min
Max. working pressure
20 BAR
Cooling medium flow type
Blowing
Connection thread diameter
1 Inch
Thermostat working temperature
38 - 50
Manufacturer
Emmegi

Oil coolers or heat exchangers are used to increase the exchange of heat between oil and ambient air. The coolers are fitted with a thermostat 38-50°C as standard. A controlled oil temperature increases the efficiency and lifetime of components in the system.
Emmegi
Emmegi is a supplier of agricultural machinery components, including hydraulic cylinders and power transmission systems. The brand specializes in high-performance parts for tractors and harvesting equipment. Its products are known for precision engineering and long service life. Shop more than 329 genuine Emmegi spare parts.
