Emmegi - OK2MV324301 - Oil-Cooler (24v) 48-60°c MV-3
Emmegi - OK2MV324301 - Oil-Cooler (24v) 48-60°c MV-3
Emmegi - OK2MV324301 - Oil-Cooler (24v) 48-60°c MV-3
Emmegi - OK2MV324301 - Oil-Cooler (24v) 48-60°c MV-3
Emmegi - OK2MV324301 - Oil-Cooler (24v) 48-60°c MV-3
Emmegi - OK2MV324301 - Oil-Cooler (24v) 48-60°c MV-3

In stock - ready to ship

Order now for delivery between 25 May and 28 May
Free shipping

Pay Securely with

Emmegi - OK2MV324301 - Oil-Cooler (24v) 48-60°c MV-3

Emmegi - OK2MV324301 - Oil-Cooler (24v) 48-60°c MV-3

€631.16

(Excl. VAT)

Price

(Excl. VAT)

€631.16

Product Description

Oil coolers are used to improve heat exchange between oil and environment. The 2MV coolers are fitted with a thermostat as well as a bypass as standard.
Emmegi
Emmegi is a supplier of agricultural machinery components, including hydraulic cylinders and power transmission systems. The brand specializes in high-performance parts for tractors and harvesting equipment. Its products are known for precision engineering and long service life. Shop more than 192 genuine Emmegi spare parts.

Product Details

Brand
Emmegi
Unit
Each
BWidth
465 mm
Bypass
Yes
EDepth
188 mm
Weight
10,5 kg
AHeight
409 mm
Amperage
10 A
Includes
Aluminium radiator Electric motor with impeller Temperature switch 48-60ºC Bypass Plug connection Without mounting base
Material
Plastic Aluminium
Noise level
77 dB(A)
Technical info
Air oil-coolers are applied to improve heat exchange between oil and the environment. The coolers are supplied standard with a 48 - 60 °C thermostat.
Nominal voltage
24 V
Insulation class
68
Drive motor power
260 W
Max. working flow
130 l/min
Fan outside diameter
305 mm
Max. working pressure
20 BAR
Cooling medium flow type
Suction
LMounting holes distance
310 mm
PConnection thread diameter
1 Inch
Thermostat working temperature
48-60
