Festo - MME-MTS-750-TLF-AIF-178304 - Displacement Measuring System

SKU: festo-mme-mts-750-tlf-aif-178304

Browse all parts
Festo - MME-MTS-750-TLF-AIF-178304 - Displacement Measuring System

€2,580.86€2,205.86 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 4 to 6 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€2,580.86

Brand
Festo
Stroke (mm)
750
Output Signal
CAN protocol type SPF-AIF
Housing Material
Aluminium wrought alloy, anodized
Construction Set Up
Closed profile, With Sliding carriage
Protection Category
IP65, acc. to IEC 60529
Angle Offset Carrier
± 1 °
Electrical Connection
6 pin, In compliance with DIN 45322, Round shape, Plug
Independent Linearity
0.02 %, at least ± 50 µm
Installation Position
arbitrary
Max. Power Input (mA)
90
Resolution Travel (mm)
< 0,01 mm
Assembly Clamps Material
PEI
Parallel Offset Coupling
± 1,5 mm
Ambient Temperature (°C)
-40 to 75
Max. Movement Speed (m/s)
10
Permitted Voltage Oscillations
-15 % / +20 %
Temperature Coefficient (ppm/K)
15
Nominal Operating Voltage DC (V)
24
Sliding Carriage Housing Material
PBT reinforced, Permanent magnet
Steel
Max. Movement Acceleration (m/s²)
200
Sliding Carriage Coupling Material
Aluminium die casting, painted
Oscillation Strength To DIN/IEC 68 Part 2-6
Tested to severity class 1
UKCA Marking (See Declaration Of Conformity)
Digital
CE Certificate (See Declaration Of Conformity)
to EU EMC directive
Continuous Impact Strength DIN&EC 68 Parts 2-82
Tested to severity class 1
EAN
4052568144081
Manufacturer
Festo
