Festo - NEBC-F12G8-KH-0.5-N-S-F12G8-564190 - Connection Line

SKU: festo-nebc-f12g8-kh-0-5-n-s-f12g8-564190

Browse all parts
Festo - NEBC-F12G8-KH-0.5-N-S-F12G8-564190 - Connection Line

€92.39€78.97 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€92.39

Brand
Festo
Cable Set Up
(1 x (4 x 0,14 mm²)) + 4 x 0,75 mm²
Material Note
halogenfrei
Housing Colour
black
Line Properties
Standard
Cable Length (m)
0,5
Housing Material
TPE-U(PUR)
Line Designation
Without sign holder
Special Features
Oil resistant
Based On Standard
Measurements acc. to EN 61076-2-101
Cable Diameter (mm)
8
Cable Shield Colour
Light grey
Protection Category
IP67
Screw Lock Material
brass, nickel-plated
Connection Frequency
100
Test Conditions Line
Prüfbedingungen nach Anfrage
Cable Sleeve Material
TPE-U(PUR)
LABS (PWIS) Conformity
VDMA24364-B2-L
Plug Contacts Material
brass, Gold plated
Degree Of Contamination
3
Tolerance Cable Diameter
± 0,2 mm
Ambient Temperature (°C)
-25 to 70
Bearing Temperature (°C)
-40 to 70
Insulation Sleeve Material
PP
Surge Voltage Strength (kV)
0,8
Corrosion Resistance Class KBK
1 - low corrosion stress
Operating Voltage Range DC (V)
0 to 30
Electrical Connection 1, Design
round
Electrical Connection 2, Design
round
Conductor - Nominal Cross-section
0.14 to 0.75
Electrical Connection 1, Function
Control screen
Electrical Connection 2, Function
Control screen
Electrical Connection 1, Cable Output
straight
Electrical Connection 2, Cable Output
straight
Information About Protection Category
In mounted condition
Current Carrying Capacity At 40 °C (A)
7
Electrical Connection 1, Fastening Type
Screw lock with SW14 and longitudinal knurl
Electrical Connection 2, Fastening Type
Screw lock with SW14 and longitudinal knurl
Electrical Connection 1, Connection Type
Hybrid plug
Electrical Connection 2, Connection Type
Hybrid plug
Bending Radius, Moving Cable Placement (mm)
56
Electrical Connection 1, Connection Pattern
997723
Electrical Connection 2, Connection Pattern
997723
Electrical Connection 1, Occupied Pin / Wire
8
Electrical Connection 2, Occupied Pin / Wire
8
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
Bending Radius, Permanent Cable Placement (mm)
24
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
M12x1 coded Festo specific
Electrical Connection 2, Connection Technology
M12x1 coded Festo specific
Electrical Connection 1, Number Of Pins / Wires
8
Electrical Connection 2, Number Of Pins / Wires
8
Information About Current Load Rating At 40 °C
1,5 A für Leiterquerschnitt 0,14 mm²
Ambient Temperature For Moving Cable Placements (°C)
-5 to 70
EAN
4052568260156
Manufacturer
Festo
