Festo - SFAM-90-15000L-TG112-2SV-M12-573357 - Flow Sensor

SKU: festo-sfam-90-15000l-tg112-2sv-m12-573357

Browse all parts
Festo - SFAM-90-15000L-TG112-2SV-M12-573357 - Flow Sensor

€1,644.98€1,405.97 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€1,644.98

Brand
Festo
KC-mark
KC-EMV
Permission
RCM mark, c UL us - Recognized (OL)
Display Type
Illuminating LCD blue
Control Output
2x PNP or 2x NPN adjustable
Fastening Type
pipe installation
Flow Direction
Uni-directional, From left to right
Analogue Output
0 - 10 V
Switch Function
Window comparator or threshold comparator, adjustable
Housing Material
Aluminium die casting, PA reinforced
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4], nitrogen
Presentable Unit(s)
l, l/min, m3, scf, scfm
Protection Category
IP65
Material Information
RoHs compliant
flow, Consumption
Pneumatic Connection
G1 1/2
Pressure Drop (mbar)
< 100 mbar
Electrical Connection
M12x1, 5 pin, Plug straight
Installation Position
Horizontal
Measurement Principle
Thermic
Max. Output Current (mA)
100
Medium Temperature (°C)
0 to 50
Operating Pressure (bar)
0 to 16
Short Circuit Resistance
yes
Ambient Temperature (°C)
0 to 50
Nominal Temperature (°C)
23
Switching Element Function
NC contact, NO contact
Reverse Polarity Protection
for all electrical connections
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Operating Voltage Range DC (V)
15 to 30
Pressure Dependency Clamp (%FS/b.)
0,5
Flow Measurement Range End Value (l/min)
15.000
Temperature Coefficient Clamp (± %FS/K)
type 0,1%FS/K
Min. Load Resistance Voltage Output (kOhm)
10
Output Characteristic Curve End Value (mA)
10
UKCA Marking (See Declaration Of Conformity)
UL E322346
Flow Measurement Range Starting Value (l/min)
150
CE Certificate (See Declaration Of Conformity)
acc. to EU-EMV Directive, acc. to EU-RoHS Directive
Output Characteristic Curve Starting Value (mA)
0
Flow Characteristic Curve Starting Value (l/min)
0
EAN
4052568219888
Manufacturer
Festo
