Festo - SMTO-4U-NS-K-LED-24-152837 - Proximity Switch

SKU: festo-smto-4u-ns-k-led-24-152837

Browse all parts
Festo - SMTO-4U-NS-K-LED-24-152837 - Proximity Switch

€317.26€271.16 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€317.26

Brand
Festo
Design
round
Wire Ends
Tin plated
Permission
RCM mark
Material Note
RoHs compliant
Control Output
NPN
Fastening Type
With Accessories
Housing Colour
black
Line Properties
Standard
Residual Ripple
10%
Cable Length (m)
2,5
Housing Material
PET
Voltage Drop (V)
2
Based On Standard
EN 60947-5-2
Measured Parameter
Position
Overload Resistant
Available
Repeatability (mm)
0,2
Cable Shield Colour
Grey
Protection Category
IP67
Switch On Time (ms)
5
Switch Off Time (ms)
5
Cable Sleeve Material
PVC
Installation Position
arbitrary
Measurement Principle
Inductive magnet
Residual Current (mA)
0,01
LABS (PWIS) Conformity
VDMA24364-B2-L
Max. Output Current (mA)
200
Short Circuit Resistance
Cycling
Ambient Temperature (°C)
-25 to 70
Minimum Load Current (mA)
0,1
Insulation Sleeve Material
PVC
Switching Element Function
NO contact
Switching Status Indicator
LED yellow
Connection Outlet Direction
along
Max. Tightening Torque (Nm)
0,8
Reverse Polarity Protection
for all electrical connections
Inductive Protection Circuit
Integrated
Max. Switching Capacity DC (W)
6
Operating Voltage Range DC (V)
10 to 30
Electrical Connection 1, Connection Type
cable
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
Open end
Electrical Connection 1, Number Of Pins / Wires
3
Ambient Temperature For Moving Cable Placements (°C)
-5 to 70
EAN
4052568117733
Manufacturer
Festo
