Festo - VAEM-S6-S-FAS-8-8E-549045 - AS-i Module

SKU: festo-vaem-s6-s-fas-8-8e-549045

Browse all parts
Festo - VAEM-S6-S-FAS-8-8E-549045 - AS-i Module

€374.99€320.50 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€374.99

Brand
Festo
Switch Level
Signal 1: >= 11 V
Material Note
RoHs compliant
Seals Material
PUR
Addressing Area
Einstellung durch AS-Interface-Adressiergerät
Housing Material
PA
Operating Element
DIL switch
Relative Humidity
0 - 90 %
Fieldbus Interface
Stecker, M12x1, 4-polig
Electrical Controls
Fieldbus
Protection Category
In mounted condition
Electrical Connection
over CPX
Installation Position
arbitrary
Max. Number Of Inputs
8
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Max. Number Of Outputs
8
Switching Logic Inputs
PNP (Positive switching)
LED Display Bus Specific
Fault: AS-Interface Fehler
Ambient Temperature (°C)
-5 to 50
Bearing Temperature (°C)
-20 to 60
Load Voltage Range DC (V)
21.6 to 26.4
Max. Number Of Valve Coils
8
Quantity Slaves Per Device
2
Nominal Load Voltage DC (V)
24
Reverse Polarity Protection
for all electrical operating voltage connections
LED Display Product Specific
12/14: Schaltzustand Ventile (auf Ventil)
Residual Ripple AS Interface
<= 20 mVss
Residual Ripple Load Voltage
4 Vss
Corrosion Resistance Class KBK
0 - No corrosion stressing
Max. Number Of Valve Positions
8 bei monostabilen Ventilen
Permitted Voltage Oscillations
± 10 %
Nominal Operating Voltage DC (V)
24
Operating Voltage DC AS-interface (V)
26.5 to 31.6
Nominal Operating Voltage DC AS-Interface (V)
26,5
CE Certificate (See Declaration Of Conformity)
to EU low voltage directive
EAN
4052568190293
Manufacturer
Festo
