INA FAG - GIL60UK2RSA - Rod End

OEM Supplier

SKU: ina-fag-gil60uk2rsa

INA FAG - GIL60UK2RSA - Rod End

Last known price:

€617.60

Request a Quote

Pay Securely with

Request a Quote

The INA-FAG GIL60-UK-2RS-A is a high-quality, maintenance-free rod end bearing, designed for demanding industrial and agricultural applications. It features integral 2RS seals for superior protection against contaminants and extended service life. This male rod end has a 60mm bore diameter and an M60x2 right-hand thread, offering robust articulation and excellent load carrying capacity with a basic dynamic load rating of 100 kN and a basic static load rating of 160 kN.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
gil60uk2rsa
Bore Diameter (mm)
60
Thread Size
M60x2
Thread Direction
right-hand
Thread Type
male
Overall Length (mm)
225
Length To Center (mm)
180
Head Diameter (mm)
120
Head Width (mm)
36
Inner Ring Width (mm)
44
Basic Dynamic Load Rating (kN)
100
Basic Static Load Rating (kN)
160
Weight (kg)
3.3
Sealing Type
2RS (integral seals)
Maintenance
maintenance-free
Quality
OEM Supplier
Manufacturer
ina-fag
