INA FAG - RCJY50N - Bearing Block 4 Holes

OEM Supplier

SKU: ina-fag-rcjy50n

INA FAG - RCJY50N - Bearing Block 4 Holes

€63.54

(excl. VAT)

In stock - ready to ship

Ships within 82 hours

Shipping fee: €6.00 excl. VAT

Pay Securely with

Price

(Excl. VAT)

€63.54

The INA-FAG RCJY50N is a robust Plummer Block Housing Unit designed for reliable bearing support. Featuring a 50mm bore diameter, this unit is constructed from durable cast iron and includes 4 mounting holes for secure installation. It is suitable for applications requiring a Y-bearing (insert bearing) and offers precise dimensions for various industrial and agricultural machinery.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
rcjy50n
Unit
Each
Weight
2,44 kg
Properties
Inner bearing has extended inner ring with 2 adjusting screws on both sides Can be subsequently lubricated
Total width
51,6 mm
Housing type
Square flange
ATotal length
143 mm
Housing width
143 mm
UTotal height
60,6 mm
THousing height
39 mm
Mounting holes distance
111 mm
Basic radial load static
23200 N
KMounting holes diameter
18 mm
dBearing inside diameter
50 mm
Basic radial load dynamic
35000 N
LBearing inner ring width
51,6 mm
Grease nipple thread diameter
M6
Bearing balls distance to locking side end
28 mm
EAN
4012802804751
Manufacturer
INA/FAG
