INA FAG - RME60 - Bearing Block RME 60

OEM Supplier

SKU: ina-fag-rme60

INA FAG - RME60 - Bearing Block RME 60

€147.92

(excl. VAT)

In stock - ready to ship

Ships within 57 hours

Shipping fee: €6.00 excl. VAT

Pay Securely with

Price

(Excl. VAT)

€147.92

The INA-FAG RME60 plummer block housing is a robust grey cast iron unit designed to accommodate 60mm diameter shafts. It is suitable for mounting self-aligning ball bearings and spherical roller bearings from series 12, 22, 222, and 223. This RME series housing provides reliable support and protection in various industrial applications, featuring precise dimensions for secure installation.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
rme60
OEM Part Numbers

Koyo

Timken

Asahi

Dodge

Sealmaster

Link Belt

Cooper

Mcgill

Nachi

Peer

Rexnord

Rollway

Torrington

Unit
Each
Weight
4,04 kg
Benefits
Precise axis alignment possible Fixing points are relieved
Properties
Inner bearing has extended inner ring with clamp ring on both sides Can be subsequently lubricated
Consists of
• Bearing block Clamp ring
Total width
77,9 mm
Housing type
Round flange
Total height
45,9 mm
Housing width
195 mm
THousing height
29 mm
Bearing material
Steel
CFlange thickness
16 mm
ZFitting edge diameter
135 mm
Basic radial load static
36000 N
KMounting holes diameter
18 mm
dBearing inside diameter
60 mm
Basic radial load dynamic
56000 N
LBearing inner ring width
77,9 mm
Grease nipple thread diameter
M6
Locking ring outside diameter
84 mm
EAN
4012802837681
Manufacturer
INA/FAG
