INA FAG - UCF214 - Housing Unit UCF

OEM Supplier

SKU: ina-fag-ucf214

INA FAG - UCF214 - Housing Unit UCF

€102.06

(excl. VAT)

In stock - ready to ship

Ships within 48 hours
Free shipping

Pay Securely with

Price

(Excl. VAT)

€102.06

These square ball bearing units with four bolt holes are pre-assembled and pre-lubricated. This makes them rapidly deployable. The self-aligning spherical outer ring of the wide inner ring ball bearing compensates for shaft misalignment.
INA FAG
Ina-fag is a supplier of precision bearings and components for agricultural machinery. The brand offers high-quality bearings for tractors, harvesters, and other heavy-duty equipment. Ina-fag products are engineered to withstand harsh farming conditions and reduce maintenance needs. Shop more than 17,174 genuine Ina-fag spare parts.

Brand
INA/FAG
Part Numbers
ucf214
Aftermarket Part Numbers

Skf

Ntn

Koyo

Pros
Highly suitable for limited installation spaces Assembled, ready for use Pre-lubricated
Unit
Each
Includes
Bearing block Bearing Grease nipple
Properties
Inner bearing has extended inner ring with 2 adjusting screws on both sides Can be subsequently lubricated
Housing type
Square flange
Total height
75,4 mm
aTotal length
193 mm
aHousing width
193 mm
lHousing height
54 mm
Mounting holes diameter
19 mm
Basic radial load static
44000 N
dBearing inside diameter
70 mm
eMounting holes distance
152 mm
Basic radial load dynamic
66000 N
BiBearing inner ring width
74,6 mm
Grease nipple thread diameter
M6
Bearing balls distance to locking side end
31 mm
lBearing balls distance to mounting surface
30,2 mm
EAN
4047643261265
Manufacturer
INA/FAG
