JORC - 2303 - Jorc ez1 g1/2 230vac
JORC - 2303 - Jorc ez1 g1/2 230vac
JORC - 2303 - Jorc ez1 g1/2 230vac
JORC - 2303 - Jorc ez1 g1/2 230vac

In stock - ready to ship

Order now for delivery between 21 May and 25 May
Free shipping on orders over €60

Pay Securely with

JORC - 2303 - Jorc ez1 g1/2 230vac

JORC - 2303 - Jorc ez1 g1/2 230vac

€44.90

(Excl. VAT)

Price

(Excl. VAT)

€44.90

Product Details

Brand
JORC
Timer
PCB / SMD technology ensures production consistency
Remark
Time-controlled condensate drain
Valve seal
FPM
Valve type
2/2 way, directly controlled
Weight [kg]
0.495
Rated voltage
230 VAC
Test function
yes
Plug connection
DIN 43650-A
System pressure
0 to 16 bar
Inlet connection
1/2" (BSP or NPT)
Protection class
IP65 (NEMA4)
Inlet height [mm]
10
Outlet connection
1/2" (BSP or NPT)
Housing - Material
ABS plastic FR class
Maintainable valve
yes
Medium temperature
+1°C to +55°C
Ambient temperature
+1°C to +55°C
Time cycle (On/Off)
0.5 - 10 sec (On) / 0.5 - 45 min (Off)
Cycle indicator timer
LED, glowing yellow
max. compressor power
unlimited
Valve housing material
Brass (stainless steel available, see FLUIDRAIN)
Valve nominal width [mm]
4
Manufacturer
JORC
