Voss - GES28LM33 - Coupling 28l M33

Voss - GES28LM33 - Coupling 28l M33

Voss - GES28LM33 - Coupling 28l M33

Voss - GES28LM33 - Coupling 28l M33

Voss - GES28LM33 - Coupling 28l M33

Voss - GES28LM33 - Coupling 28l M33

Number of products

In stock - ready to ship

Order now for delivery between 16 May and 20 May

Free shipping on orders over €60

Pay Securely with

Voss - GES28LM33 - Coupling 28l M33

Voss - GES28LM33 - Coupling 28l M33

€5.51

(Excl. VAT)

Price

(Excl. VAT)

€5.51

Number of products

Voss

Voss is a supplier of industrial and agricultural components, including hydraulic systems and fittings. The brand's products are used in tractor attachments, irrigation systems, and other farm machinery requiring reliable fluid handling. Its solutions ensure high performance and durability in demanding agricultural applications. Shop more than 2,632 genuine Voss spare parts.

Product Details

Brand

Pros

Reduced risk of leakage

Unit

Each

Shape

Straight - 2 connection sides

Length

43 mm

Series

28L

DIN standard

2353 228 3852 2401

ISO standard

228

Pipe diameter

28 mm

Inside diameter

23 mm

Surface treatment

Zinc Nickel

Connection 2, type

Thread

Connection no 1 type

Cutting ring

Max working pressure

200 BAR

Max. tightening torque

400 N·m

Connection no 1 diameter

28 mm

Connection no 1 hex size

39 mm

Connection 2, thread type

Metric

Connection no 1 thread type

Metric

S2Connection 2, wrench size

41.0 mm

d1Connection 2, thread pitch

2.00 mm

S1Connection no 1 wrench size

41.0 mm

KConnection no 1 thread length

18 mm

d2Connection no 1 thread pitch

2.00 mm

d1Connection 2, thread diameter

M36

Connection 2, type - male/female

Male

d2Connection no 1 thread diameter

33 mm

Connection no 1 type - male/female

Male

L1Connection 2, centre to end distance

17,5 mm

L2Connection no 1 center to end distance

34 mm

Manufacturer

Voss
