Voss - RSWV12LM16 - Coupling
Voss - RSWV12LM16 - Coupling
Voss - RSWV12LM16 - Coupling
Voss - RSWV12LM16 - Coupling

In stock - ready to ship

Order now for delivery between 16 May and 20 May
Free shipping on orders over €60

Pay Securely with

Voss - RSWV12LM16 - Coupling

Voss - RSWV12LM16 - Coupling

€9.75

(Excl. VAT)

Price

(Excl. VAT)

€9.75

Product Description

Genuine VOSS Fluid RSWV12LM16 light series swivel coupling, designed for hydraulic systems. This high-quality fitting connects a 12mm outer diameter tube to an M16x1.5 threaded port, allowing for angular adjustment and reducing stress on connections. Manufactured from durable zinc-plated steel, it ensures reliable performance and leak-free operation in demanding industrial and agricultural applications.
Voss
Voss is a supplier of industrial and agricultural components, including hydraulic systems and fittings. The brand's products are used in tractor attachments, irrigation systems, and other farm machinery requiring reliable fluid handling. Its solutions ensure high performance and durability in demanding agricultural applications. Shop more than 2,632 genuine Voss spare parts.

Product Details

Brand
Voss
Unit
Each
Angle
90 °
Shape
Elbow - 2 connection sides
Series
12L
L3Length
38,5 mm
DIN standard
2353 228 3852 2401
ISO standard
228
Pipe diameter
12 mm
Seal material
Metal
Product details
2S cutting ring Optimal cutting ring connection and functionality Multiple corrosion resistance Adjustable direction
Surface treatment
Zinc Nickel
Connection 2, type
Banjo
Connection no 1 type
Cutting ring
Max working pressure
400 BAR
Connection no 1 diameter
12 mm
Connection 2, thread type
Metric
Connection 2, thread pitch
1.50 mm
S3Connection 2, wrench size
22.0 mm
Connection no 1 thread pitch
1.50 mm
DConnection no 1 wrench size
22.0 mm
Connection 2, thread diameter
M16
KConnection no 1 thread length
12 mm
Connection no 1 thread diameter
M18
Connection 2, type - male/female
Male
Connection no 1 type - male/female
Male
Connection centre to insert distance
16,5 mm
L1Connection no 1 center to end distance
33 mm
Manufacturer
Voss
