Casappa - PLM2020R82E2 - +Hydraulic motor 19.5cc
Casappa - PLM2020R82E2 - +Hydraulic motor 19.5cc
Casappa - PLM2020R82E2 - +Hydraulic motor 19.5cc
Casappa - PLM2020R82E2 - +Hydraulic motor 19.5cc
Casappa - PLM2020R82E2 - +Hydraulic motor 19.5cc
Casappa - PLM2020R82E2 - +Hydraulic motor 19.5cc

In stock - ready to ship

Order now for delivery between 22 May and 26 May
Free shipping

Pay Securely with

Casappa - PLM2020R82E2 - +Hydraulic motor 19.5cc

Casappa - PLM2020R82E2 - +Hydraulic motor 19.5cc

€188.61

(Excl. VAT)

Price

(Excl. VAT)

€188.61

Casappa
Casappa specializes in hydraulic systems and components for agricultural machinery, including pumps, motors, and valves. The brand is known for its high-performance solutions that enhance the efficiency of tractors and farming equipment. Its products are widely used in irrigation systems, harvesters, and other heavy-duty agricultural applications. Shop more than 567 genuine Casappa spare parts.

Product Details

Brand
Casappa
Unit
Each
Details
Various connection options
Benefits
Wide range of applications Can be used in challenging environmental conditions
Properties
Electrohydraulic ventilator drive Customer-specific design possible
Shaft type
Tapered
Flange code
E2
Displacement
21,14 cm³/rev
Port position
End
Housing length
117,5 mm
Pump group code
3
Flange type norm
European
Housing material
Aluminium
Application range
Mobile applications Industrial applications
Max pressure peak
204 BAR
Shaft thread type
Metric fine
Max rotation speed
3000 r/min
Min rotation speed
500 r/min
Shaft thread pitch
1.50 mm
Main port size code
2G08
Shaft cone size code
1:8
Shaft thread diameter
M12
Pressure port size code
1G08
Number of mounting holes
4
Flange and back cover material
Steel
Max. continous working pressure
170 BAR
Max intermittend working pressure
187 BAR
DSuction port bolts circle diameter
30 mm
EPressure port bolts circle diameter
40 mm
Manufacturer
Casappa
