Di Natale Bertelli - TC3063 - Telescopic Cylinder TC 3063 Ball
Di Natale Bertelli - TC3063 - Telescopic Cylinder TC 3063 Ball
Di Natale Bertelli - TC3063 - Telescopic Cylinder TC 3063 Ball
Di Natale Bertelli - TC3063 - Telescopic Cylinder TC 3063 Ball
Di Natale Bertelli - TC3063 - Telescopic Cylinder TC 3063 Ball

In stock - ready to ship

Order now for delivery between 23 May and 27 May
Free shipping

Pay Securely with

Di Natale Bertelli - TC3063 - Telescopic Cylinder TC 3063 Ball

Di Natale Bertelli - TC3063 - Telescopic Cylinder TC 3063 Ball

€379.71

(Excl. VAT)

Price

(Excl. VAT)

€379.71

Product Description

The Di Natale-Bertelli TC3063 is a genuine single-acting telescopic cylinder designed with a ball joint, commonly used in agricultural trailer applications. It features a 1000 mm stroke, a closed length of 630 mm, and a barrel diameter of 90 mm. The ball joint has a diameter of 30 mm, and the unit weighs 11.5 kg, ensuring robust and reliable hydraulic operation.
Di Natale Bertelli

Product Details

Brand
Di Natale-Bertelli
Unit
Each
Stroke
790 mm
Weight
22 kg
Properties
Unpainted Low installation dimensions Excellent running properties Long service life
DIN standard
1629
LMin. length
360 mm
Oil capacity
3,2 l
Number of stages
4
Sealing material
Polyurethane
Stage 1 diameter
46 mm
Stage 2 diameter
61 mm
Stage 3 diameter
76 mm
Stage 4 diameter
91 mm
Application range
Trailer tipping cylinder Vehicle construction
Cylinder material
Steel S355J2+N
DOutside diameter
112 mm
Max. piston speed
0,5 m/s
Application category
Telescopic
CSide shaft diameter
35 mm
Max. working pressure
180 BAR
Vickers hardness (HV)
HV5/12=500/550
BOil connection length
40 mm
Max. capacity - stage 2
5,2 t
Max. capacity - stage 3
8,1 t
Max. capacity - stage 4
11,7 t
Max. capacity at 180 bar
11,7 t
Oil connection thread type
Metric
Oil connections thread pitch
1.50 mm
Mounting type - rod connection
Ball
Oil connection thread diameter
M18
Piston surface roughness range
0.05-0.15 µm
IMounting bush outside diameter
112 mm
Mounting type - cylinder connection
Trunnion
C1Oil connection to rod end distance
140 mm
FMounting hole to swivel tap distance
220 mm
HMounting hole diameter - rod connection
45 mm
Mounting hole diameter - cylinder connection
40 mm
Manufacturer
Di Natale-Bertelli
