Emmegi - OK2030K24201 - Emmegi Oil Cooler (24 V) 38-50'C 2030K-24-2-01

SKU: emmegi-ok2030k24201

Emmegi - OK2030K24201 - Emmegi Oil Cooler (24 V) 38-50'C 2030K-24-2-01

€690.04€589.78 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 2 to 4 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€690.04

Brand
Part Numbers
OK2030K24201
Pros
Compact flush mounting Complete unit Increased efficiency Long component service life
Unit
Each
Depth
211 mm
Weight
14 kg
Includes
Aluminium radiator Support Impeller/electric motor, voltage according to version Temperature switch Connector for connecting temperature switch/DC motor
Noise level
68 dB(A)
Technical info
Air oil-coolers are applied to improve heat exchange between oil and the environment. The coolers are supplied standard with a 40 - 48 °C thermostat.
Nominal voltage
24 V
Product details
Temperature switch 38-50°C Maximum temperature 120°C The motor must be switched via a relay
Insulation class
65
Long description
Oil coolers or heat exchangers are used to increase the exchange of heat between oil and ambient air. The coolers come as standard with a 38-50°C thermostat. A controlled oil temperature increases the efficiency and lifetime of the components in the system.
Max. working flow
130 l/min
Fan outside diameter
305 mm
Max. working pressure
20 BAR
Cooling medium flow type
Suction
Connection thread diameter
1 Inch
Thermostat working temperature
38 - 50
Manufacturer
Emmegi

Oil coolers or heat exchangers are used to increase the exchange of heat between oil and ambient air. The coolers come as standard with a 38-50°C thermostat. A controlled oil temperature increases the efficiency and lifetime of the components in the system.
Emmegi
Emmegi is a manufacturer known for its components used in various industrial and agricultural applications. While specific founding details are not widely publicized, the company has established itself as a supplier of robust parts, often found in hydraulic and cooling systems. Its products are designed to meet the demanding requirements of heavy machinery. The brand's product lines typically include heat exchangers, oil-air coolers, and hydraulic components. These are critical for maintaining optimal operating temperatures and ensuring efficient power transmission in machinery. Emmegi components are often integrated into larger systems, providing reliable performance in challenging environments. At Partao, you can find a comprehensive selection of Emmegi spare parts, including Brackets & Supports, Control Modules, Cooling Fans, Doors & Panels, and Hoses & Fittings. Emmegi parts are frequently chosen by equipment manufacturers and operators seeking durable and efficient solutions for their hydraulic and cooling needs. The reliability of its components contributes to the overall longevity and performance of the machinery they are installed in, making them a practical choice for maintenance and repair. Shop more than 329 genuine Emmegi spare parts.
