Festo - ESS-6-SS-189276 - Vacuum Sucker

SKU: festo-ess-6-ss-189276

Browse all parts
Festo - ESS-6-SS-189276 - Vacuum Sucker

€15.69€13.41 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€15.69

Brand
Festo
Colour
transparent
Material Note
RoHs compliant
Stud Material
Nickel-plated brass
Fastening Type
Via vacuum connection
Shore Hardness
50 ± 5
Operating Medium
Atmospheric air based on ISO 8573-1:2010 [7:-:-]
Suction Cup Shape
Round flat
Vacuum Connection
Inside diameter 4 mm
Food Compatibility
See expanded material information
Nominal Width (mm)
2
Operating Pressure
-0,095 to 0
Suction Cup Volume
0,015
Connection Position
top
Installation Position
arbitrary
Suction Cups Material
VMQ (Silicone)
LABS (PWIS) Conformity
VDMA24364-Zone III
Ambient Temperature (°C)
-30 to 180
Suction Cup Diameter (mm)
6
Min. Workpiece Radius (mm)
15
Nominal Operating Pressure
-0,07
Allocate Suction Cup Fixation
Size 2
Corrosion Resistance Class KBK
1 - low corrosion stress
Ejection Impulse Plausibility (bar)
4
Shear Force For Nominal Operating Pressure (N)
2,5
Holding Force For Nominal Operating Pressure (N)
1,10
EAN
4052568041939
Manufacturer
Festo
