Festo - KS3-CK-6-3478 - Coupling Plug

SKU: festo-ks3-ck-6-3478

Browse all parts
Festo - KS3-CK-6-3478 - Coupling Plug

€8.41€7.19 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€8.41

Brand
Festo
Material Note
RoHs compliant
Operating Medium
Compressed air to ISO 8573-1:2010 [7:-:-]
Nominal Width (mm)
4,9
Locking Nut Material
Aluminium-Knetlegierung, eloxiert
Material Information
brass, nickel-plated
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 1
für Stecknippel Innen-Ø 6 mm mit Überwurfmutter
Ambient Temperature (°C)
-10 to 60
Corrosion Resistance Class KBK
1 - low corrosion stress
Note On Operating And Control Medium
Oiled operation possible
Operating Pressure Complete Temperature Range (MPa)
-0,095 to 1,2
Nominal Flow Rate Standardised According To ISO 8778
234,1 to 503
Standard Nominal Flow Rate (Standardised To DIN 1343)
216 to 464
EAN
4052568018238
Manufacturer
Festo
