Festo - NECU-G78G5-C2-543107 - Power Connection Socket

SKU: festo-necu-g78g5-c2-543107

Browse all parts
Festo - NECU-G78G5-C2-543107 - Power Connection Socket

€64.57€55.19 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€64.57

Brand
Festo
Permission
c CSA us (OL)
Plug Coding
NFPA/T3.5.29 R1-2003
Housing Colour
black
Seals Material
FKM, NBR
Housing Material
PA
Based On Standard
EN 61984
Protection Category
IP67
Locking Nut Material
nickel-plated, Zinc pressure cast
Material Information
Copper and PTFE-free, RoHs compliant
1 - low corrosion stress
LABS (PWIS) Conformity
3
Plug Contacts Material
Copper allow, Gold plated
Electrical Connection 1
Straight socket, 7/8", 5-pin
Electrical Connection 2
Screw clamp
Ambient Temperature (°C)
-25 to 80
Current Carrying Capacity (A)
8
Permitted Cable Diameter (mm)
6 to 12
Operating Voltage Range AC (V)
0 to 250
Operating Voltage Range DC (V)
0 to 250
Connection Cross-section (mm²)
<= 1,5 mm2
CE Certificate (See Declaration Of Conformity)
to EU low voltage directive
EAN
4052568091231
Manufacturer
Festo
