Festo - SMTO-1-PS-S-LED-24-C-151685 - Proximity Switch

SKU: festo-smto-1-ps-s-led-24-c-151685

Browse all parts
Festo - SMTO-1-PS-S-LED-24-C-151685 - Proximity Switch

€202.12€172.75 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€202.12

Brand
Festo
Design
Block structure
Permission
RCM mark
Material Note
RoHs compliant
Control Output
PNP
Fastening Type
With Accessories
Housing Colour
black
Hysteresis (mm)
0,1 to 1,5
Residual Ripple
10%
Housing Material
Zinc pressure cast
Voltage Drop (V)
3
Based On Standard
EN 60947-5-2
Measured Parameter
Position
Overload Resistant
Available
Repeatability (mm)
0,2
Protection Category
IP67
Switch On Time (ms)
1
Switch Off Time (ms)
1
Installation Position
arbitrary
Measurement Principle
Inductive magnet
Residual Current (mA)
0,01
LABS (PWIS) Conformity
VDMA24364-B2-L
Plug Contacts Material
brass, Gold plated
Max. Output Current (mA)
200
Short Circuit Resistance
Cycling
Ambient Temperature (°C)
-25 to 70
Switching Element Function
NO contact
Switching Status Indicator
LED yellow
Connection Outlet Direction
along
Reverse Polarity Protection
for all electrical connections
Inductive Protection Circuit
adjusted to MZ, MY, ME coils
Max. Switching Capacity DC (W)
6
Max. Switching Frequency (kHz)
1000
Operating Voltage Range DC (V)
10 to 30
Electrical Connection 1, Fastening Type
nicht drehbar
Electrical Connection 1, Connection Type
Plug
Electrical Connection 1, Connection Pattern
991155
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
M8x1, A coded to EN 61076-2-104
Electrical Connection 1, Number Of Pins / Wires
3
Electrical Connection 1, Compatible Type Of Mounting
Kompatibel mit Schraubverriegelung drehbar
EAN
4052568117054
Manufacturer
Festo
