JORC - 1663 - Jorc fluidrain g1/2 4.5 v 24vac
JORC - 1663 - Jorc fluidrain g1/2 4.5 v 24vac
JORC - 1663 - Jorc fluidrain g1/2 4.5 v 24vac
JORC - 1663 - Jorc fluidrain g1/2 4.5 v 24vac
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping on orders over €60

Pay Securely with

JORC - 1663 - Jorc fluidrain g1/2 4.5 v 24vac

JORC - 1663 - Jorc fluidrain g1/2 4.5 v 24vac

€58.43

(Excl. VAT)

Price

(Excl. VAT)

€58.43

Product Details

Brand
JORC
Timer
PCB / SMD technology ensures production consistency
Remark
Time-controlled condensate drain
Valve seal
FPM
Valve type
2/2-way, directly controlled
Rated voltage
24 VAC
Test function
yes
Plug connection
DIN 43650-A
System pressure
0 to 16 bar
Inlet connection
1/2" (BSP or NPT)
Protection class
IP65 (NEMA4)
Inlet height [mm]
10
Outlet connection
1/2" (BSP or NPT)
Maintainable valve
yes
Medium temperature
+1°C to +55°C
Ambient temperature
+1°C to +55°C
Cycle display timer
bright LED lighting
Time cycle (On/Off)
0.5 - 10 sec / 0.5 - 45 min (depending on timer model)
max. compressor power
unlimited
Valve housing material
Brass (stainless steel available)
Valve nominal width [mm]
4.5
Manufacturer
JORC
