Kramp - D162555CW0R - Cylinder Quick Change CW0 Right
Kramp - D162555CW0R - Cylinder Quick Change CW0 Right
Kramp - D162555CW0R - Cylinder Quick Change CW0 Right
Kramp - D162555CW0R - Cylinder Quick Change CW0 Right
Kramp - D162555CW0R - Cylinder Quick Change CW0 Right
Kramp - D162555CW0R - Cylinder Quick Change CW0 Right

In stock - ready to ship

Order now for delivery between 20 May and 23 May
Free shipping

Pay Securely with

Kramp - D162555CW0R - Cylinder Quick Change CW0 Right

Kramp - D162555CW0R - Cylinder Quick Change CW0 Right

€72.63

(Excl. VAT)

Price

(Excl. VAT)

€72.63

Product Description

The Kramp D162555CW0R is a genuine Kramp cylinder designed for quick change systems, specifically the CW0 right configuration. Constructed from durable steel with a black finish, this cylinder features a screw mounting type. Its dimensions are 260mm in length, 100mm in width, and 100mm in height, with a total weight of 1.1 kg. It includes an M10 thread with a 1.5mm pitch, two 10.5mm diameter holes spaced 60mm apart, and a 20mm diameter, 20mm long pin. It is rated for a maximum load of 500 kg, ensuring robust performance in agricultural and industrial applications.
Kramp
Kramp is a leading distributor of spare parts and accessories for agricultural machinery. Their catalog includes wear parts, belts, and maintenance items for tractors and implements. Kramp ensures quick availability of critical components for farming operations. Shop more than 86,606 genuine Kramp spare parts.

Product Details

Brand
Kramp
Type
Double acting
Unit
Each
Stroke
55 mm
Min. length
144 mm
Rod diameter
16 mm
Rod material
Steel 20MnV6 Steel C45
Inside diameter
25 mm
Long description
Cylinder Quick release, type CW
Outside diameter
35 mm
Cylinder material
Stainless steel 52.0
Head nut material
Steel
Mounting head width
48 mm
Application category
Quick release
Mounting head length
70 mm
Max. working pressure
250 BAR
Rod surface roughness
0,25 µm
Rod surface treatment
Chromated
Mounting type - rod connection
Bore
Cylinder end to rod end distance
176 mm
Mounting type - cylinder connection
Flange
Cylinder material tolerance class code
H10
Mounting hole diameter - rod connection
8,5 mm
Mounting diameter (width) - rod connection
8,5 mm
Mounting hole diameter - cylinder connection
9 mm
Mounting holes distance - cylinder connection
30 mm50 mm
Mounting thread diameter - cylinder connection
1/4 Inch
Mounting diameter (width) - cylinder connection
9 mm
Manufacturer
Kramp
