Mac Power - GIR20DO - Rod End
Mac Power - GIR20DO - Rod End
Mac Power - GIR20DO - Rod End
Mac Power - GIR20DO - Rod End

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping on orders over €60

Pay Securely with

Mac Power - GIR20DO - Rod End

Mac Power - GIR20DO - Rod End

€11.27

(Excl. VAT)

Price

(Excl. VAT)

€11.27

Product Details

Brand
Mac Power
Unit
Each
Properties
Requires maintenance Lubricated connection steel/steel
BHole length
16 mm
Thread pitch
1.50 mm
ßEdge angle
9 °
L5Height base
10 mm
L4Total height
103,5 mm
Technical info
Upward of 25mm bore nipple screwed in
dHole diameter
20 mm
L3Thread length
40 mm
D4Shaft diameter
27,5 mm
Thread direction
Right
Application range
Agricultural machines Cylinder Articulated points Suspension
D3Thread diameter
M20
Surface treatment
Zinc-plated
WBase outside diameter
32 mm
DBearing outside diameter
35 mm
C1Head width (hole length)
13 mm
L7Shaft to center distance
27 mm
D1Outside diameter of inner ring
24,1 mm
H1Hole centre to bottom distance
77 mm
Manufacturer
Mac Power
